130 Rockwell Automation Publication 1769-IN088A-EN-P - February 2011
Chapter 3 I/O Memory Mapping
Configuration Data File
The manipulation of the bits from this file is normally done with programming
software, such as RSLogix 500, RSLogix 5000, or RSNetWorx for DeviceNet,
during initial configuration of the system. In that case, graphical screens are
provided by the programmer to simplify configuration. However, some systems,
like the 1769-ADN DeviceNet adapter, also allow the bits to be altered as part of
the control program, using communication rungs. In that case, it is necessary to
understand the bit arrangement. The channel configuration words, words 0 and
1, are described on page 131. Refer to the Compact Analog I/O User Manual,
publication number 1769-UM002
for additional details.
Word
Bit Position
1514131211109876543210
0 See “Channel Configuration Words” on page 131.
1 See “Channel Configuration Words” on page 131.
2 S Fault Value - Channel 0
(1)
(1) These functions are not supported by all controllers, such as MicroLogix 1500, using any configuration method.
Refer to your controller’s user manual for details.
3 S Program (Idle) Value - Channel 0
4 S Fault Value - Channel 1
5 S Program (Idle) Value - Channel 1
To Next Page
