Rockwell Automation Publication 1769-IN088A-EN-P - February 2011 75
I/O Memory Mapping Chapter 3
Controller Tags for RSLogix 5000, Version 15 or Later
Use the following controller tags with RSLogix 5000, version 15 or later.
Channel 0 and 1 Configuration Data
Channel 0 and 1 configuration data is shown below. The same information
applies to all channels.
- Local:1:C AB:1769_IF8:C:0
+ Local:1:C.RTSInterval INT Decimal
Local:1:C.RTSEn BOOL Decimal
+ Local:1:C.Ch0Filter SINT Decimal
Local:1:C.Ch0AlarmInterruptEn BOOL Decimal
Local:1:C.Ch0AlarmLatchEn BOOL Decimal
Local:1:C.Ch0AlarmEn BOOL Decimal
Local1:C.Ch0En BOOL Decimal
+ Local:1:C.Ch0Range SINT Decimal
+ Local:1:C.Ch0DataFormat SINT Decimal
+ Local:1:C.Ch0HAlarmLimit INT Decimal
+ Local:1:C.Ch0LAlarmLimit INT Decimal
+ Local:1:C.Ch0AlarmDeadband INT Decimal
+ Local:1:C.Ch1Filter SINT Decimal
Local:1:C.Ch1AlarmInterruptEn BOOL Decimal
Local:1:C.Ch1AlarmLatchEn BOOL Decimal
Local:1:C.Ch1AlarmEn BOOL Decimal
Local:1:C.Ch1En BOOL Decimal
+ Local:1:C.Ch1Range SINT Decimal
+ Local:1:C.Ch1DataFormat SINT Decimal
+ Local:1:C.Ch1HAlarmLimit INT Decimal
+ Local:1:C.Ch1LAlarmLimit INT Decimal
+ Local:1:C.Ch1AlarmDeadband INT Decimal
