Rockwell Automation Allen-Bradley 1769-OF4 Installation Instructions

76 Rockwell Automation Publication 1769-IN088A-EN-P - February 2011
Chapter 3 I/O Memory Mapping
Tag Name To Select Make These Bit Settings
(1)
(1) All bit positions left blank in table must be set to 0.
15-876543210
Ch#Filter 60 Hz 0 0 0
50 Hz 0 0 1
10 Hz 0 1 0
250 Hz 0 1 1
500 Hz 1 0 0
Ch#AlarmInterruptEn Enable 1
Disable 0
Ch#AlarmLatchEn Enable 1
Disable 0
Ch#AlarmEn Enable 1
Disable 0
Ch#En Enable 1
Disable 0
Ch#Range -10…+10V DC 0 0 0
0…5V dc 0 0 1
0…10V dc 0 1 0
4…20 mA 0 1 1
1…5V dc 1 0 0
0…20 mA 1 0 1
Ch#DataFormat Raw/proportional counts 0 0
Engineering units 0 1
Scaled for PID 1 0
Percent range 1 1
