96 Rockwell Automation Publication 1769-IN088A-EN-P - February 2011
Chapter 3 I/O Memory Mapping
1769-IQ32
The following I/O memory mapping lets you configure the 1769-IQ32 module.
Input Data File
For each input module, slot x, word 0 in the input data file contains the current
state of the field input points.
1769-IQ32T
The following I/O memory mapping lets you configure the 1769-IQ32T
module.
Input Data File
For each input module, slot x, words 0 and 1 in the input data file contain the
current state of the field input points.
Filter Time
(1)
(1) Filter Time: Word 0, the Filter Time configures the ON to OFF
and OFF to ON hardware delay times for each input group.
Bit Setting
2.0 msec 0010
1.0 msec 0011
0.5 msec 0100
0.1 msec 0101
0.0 msec 0110
Word
Bit Position
1514131211109876543210
0r
(1)
(1) r = read.
rrrrrrrrrrrrrrr
1rrrrrrrrrrrrrrrr
Word
Bit Position
1514131211109876543210
0r
(1)
(1) r = read.
rrrrrrrrrrrrrrr
1rrrrrrrrrrrrrrrr
