I/O Memory Mapping Chapter 3
Define To
Select
Make these bit settings
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Input Filter
Selection /
-3 dB
Frequency
60 Hz
0000
50 Hz 0001
5 Hz 0010
10 Hz
0011
100 Hz 0100
250 Hz 0101
500 Hz
0110
1000 Hz 0111
No
Filter
1000
Define To Select Make these bit settings
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Input
Type /
Range
Select
-10 to +10V dc
0000
0 to 5V dc
0001
0 to 10V dc
0010
4 to 20 mA
0011
1 to 5V dc
0100
0 to 20 mA
0101
Input
Data
Format
Select
Raw/
Proportional
Counts
000
Engineering
Units
001
Scaled for PID 010
Percent Range 011
Define To Select Make these bit settings
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Output
Type /
Range
Select
-10 to +10V dc
0000
0 to 5V dc
0001
0 to 10V dc
0010
4 to 20 mA
0011
1 to 5V dc
0100
0 to 20 mA
0101
Output
Data
Format
Select
Raw/
Proportional
Counts
000
Engineering
Units
001
Scaled for
PID
010
Percent
Range
011
