78 Rockwell Automation Publication 1769-IN088A-EN-P - February 2011
Chapter 3 I/O Memory Mapping
+ Local:1:I.Ch2_3Status SINT Binary
Local:1:I.Ch2OverRange BOOL Decimal
Local:1:I.Ch2UnderRange BOOL Decimal
Local:1:I.Ch2HAlarm BOOL Decimal
Local:1:I.Ch2LAlarm BOOL Decimal
Local:1:I.Ch3OverRange BOOL Decimal
Local:1:I.Ch3UnderRange BOOL Decimal
Local:1:I.Ch3HAlarm BOOL Decimal
Local:1:I.Ch3LAlarm BOOL Decimal
+ Local:1:I.Ch4_5Status SINT Binary
Local:1:I.Ch4OverRange BOOL Decimal
Local:1:I.Ch4UnderRange BOOL Decimal
Local:1:I.Ch4HAlarm BOOL Decimal
Local:1:I.Ch4LAlarm BOOL Decimal
Local:1:I.Ch5OverRange BOOL Decimal
Local:1:I.Ch5UnderRange BOOL Decimal
Local:1:I.Ch5HAlarm BOOL Decimal
Local:1:I.Ch5LAlarm BOOL Decimal
+ Local:1:I.Ch6_7Status SINT Binary
Local:1:I.Ch6OverRange BOOL Decimal
Local:1:I.Ch6UnderRange BOOL Decimal
Local:1:I.Ch6HAlarm BOOL Decimal
Local:1:I.Ch6LAlarm BOOL Decimal
Local:1:I.Ch7OverRange BOOL Decimal
Local:1:I.Ch7UnderRange BOOL Decimal
Local:1:I.Ch7HAlarm BOOL Decimal
Local:1:I.Ch7LAlarm BOOL Decimal
- Local:1:I AB:1769_IF8:I:0
