24 Rockwell Automation Publication 5069-UM007A-EN-P - February 2019
Chapter 3 Connect to the EtherNet/IP Network
• The adapter is DHCP-enabled. That is, the adapter is configured to
obtain an IP address via a DHCP server.
If there is no DHCP server or the DHCP server is not configured to set
the IP address, you must set the IP address manually.
• The adapter issues requests for an IP address via DHCP until an IP
address is set by using one of the tools that are described in this section.
• The adapter is configured so that you must set the IP address each time
that power is cycled.
You can change the adapter configuration so that you are not required to
set an IP address each time that power is cycled.
Requirements
To set the IP address, have the following:
• EtherNet/IP or USB drivers that are installed on the programming
workstation (For more information on setting drivers or IP addresses,
see ENET-UM006
)
• MAC ID from the device, which is on the label on the side of the device
• Recommended IP address for the device
Set the IP Address with the
Rotary Switches
If the network uses 192.168.1.x, use the rotary switches on the adapter to set
the last octet of network IP address. Valid numbers range from 001…254.
IMPORTANT The rotary switches only set the IP address when power is cycled.
WARNING: When you change switch settings on the adapter while power
is on, an electric arc can occur. This arc could cause an explosion in
hazardous location installations. Be sure that power is removed or the area
is nonhazardous before proceeding.
When you press the reset button on the 5069-AEN2TR adapter while power is
on, an electric arc can occur. This arc could cause an explosion in hazardous
location installations. Be sure that power is removed or the area is
nonhazardous before proceeding.
IMPORTANT: The 5069-AENTR adapter does not have a reset button.
