Rockwell Automation Allen-Bradley 5069-AENTR User Manual

Rockwell Automation Publication 5069-UM007A-EN-P - February 2019 43
Appendix A
Compact 5000 EtherNet/IP Adapter
Status Indicators
EtherNet/IP communication modules have multi-character displays and status
indicators to assist with performance and diagnostics.
5069-AENTR Adapter
Status Indicators
Figure 7 - 5069-AENTR Adapter Status Indicators
Topic Page
5069-AENTR Adapter Status Indicators 43
5069-AEN2TR Adapter Status Indicators 46
Power Status Indicators
Controller and EtherNet/IP
Status Indicators

Rockwell Automation Allen-Bradley 5069-AENTR Specifications

General

Brand	Rockwell Automation
Model	Allen-Bradley 5069-AENTR
Category	Adapter
Language	English
