Rockwell Automation Publication 5069-UM007A-EN-P - February 2019 35
Configure the Adapter Chapter 4
6. On the New Module dialog box, click the Connection category and
complete the tasks:
a. Set the Requested Packet Interval (RPI). The range is 25
…750 ms,
with 100 ms as the default. This connection is for status data only,
with no I/O.
b. Select the Connection over EtherNet/IP, Unicast, or Multicast.
For non-redundant controllers, the default value is Unicast when the
target device supports unicast; otherwise, the default value is
Multicast. For redundant controllers, the default value is Multicast
when the target device supports multicast; otherwise, the default
value is Unicast.
c. Click OK.
7. Save the project.
8. If the project does not have a communication path to the controller,
click Browse to create a path.
