Rockwell Automation Publication 2198-IN016B-EN-P - October 2018 5
Kinetix 5700 DC-bus Conditioner Module
Product Dimensions
Refer to the Kinetix 5700 Servo Drives User Manual, publication 2198-UM002, for system-wide
drill hole specifications.
DC-bus Conditioner Module Dimensions
DC-bus Conditioner Module
Cat. No.
AB
(1)
(1) The recommended mounting hardware is M5 (#10-32) steel bolts. Apply 4.0 N•m (35.4 lb•in) maximum torque to each fastener.
CD
2198-DCBUSCOND-RP312 300 (11.81) 345 (13.58) 358 (14.09) 253 (10.0)
MODULE
STATUS
A
C
55
(2.16)
D
27.5
(1.08)
27.5
(1.08)
B
MOD
DC BUS
10.0
(0.39)
29.5
(1.16)
56.3
(2.22)
2198-DCBUSCOND-RP312
DC-bus Conditioner Module
(side view)
Dimensions are in mm (in.)
