12 Rockwell Automation Publication TLP-IN001A-EN-P - October 2019

Kinetix TLP Servo Motors with 046…235 mm Frame Size

Radial Load Force Ratings (maximum) for Brake Motors

TLP-A200-350-Dxxx2x 3000 –91.9–––68.0–57.0–50.3–––––

TLP-A200-450-Dxxx2x 3000 –91.9–––68.0–57.0–50.3–––––

TLP-A200-550-Dxxx2x 3000 –91.9–––68.0–57.0–50.3–––––

TLP-A200-750-Dxxx2x 2500 –91.9–––68.0–57.0–50.3–––––

TLP-A235-11K-Dxxx2x 2000 136.5–101.0––84.774.8––––––––

TLP-A235-15K-Dxxx2x 2000 136.5–101.0––84.774.8––––––––

(1) 1.0 kgf = 2.2 lbf or 9.8 N.

Motor

Cat. No.

(1)

(1) 1.0 kgf = 2.2 lbf or 9.8 N.

Speed, max

rpm

RPM

500

kgf

750

kgf

1000

kgf

1125

kgf

1250

kgf

1500

kgf

2000

kgf

2250

kgf

2500

kgf

3000

kgf

3375

kgf

3750

kgf

4500

kgf

5000

kgf

6000

kgf

TLP-A046-005-Dxxx4x 6000 –––––10.5–––8.4––7.3–6.6

TLP-A046-010-Dxxx4x 6000 –––––10.9–––8.7––7.6–6.9

TLP-A070-020-Dxxx4x 6000 –––––26–––20.6––18–16.4

TLP-A070-040-Dxxx4x 6000 –––––27.3–––21.7––18.9–17.2

TLP-A090-075-Dxxx4x 6000 –––––39.3–––31.2––27.2–24.7

TLP-A100-100-Dxxx4x 3000 –65.3–––51.8–45.3–41.1–––––

TLP-A115-100-Dxxx4x 5000 ––––57.9–––45.9––40.1–36.4–

TLP-A115-200-Dxxx4x 5000 ––––60.3–––47.8––41.8–38–

TLP-A145-050-Dxxx4x 3000 –120.3–––95.5–83.4–75.8–––––

TLP-A145-090-Dxxx4x 2000 142.1–112.8––98.589.5––––––––

TLP-A145-100-Dxxx4x 3000 –120.3–––95.5–83.4–75.8–––––

TLP-A145-150-Dxxx4x 3000 –124.1–––98.5–86–78.2–––––

TLP-A200-200-Dxxx4x 3000 – 140.4 – – – 111.4 – 97.3 – 88.4 –––––

TLP-A200-300-Dxxx

4x 2500 – 149.7 – – – 118.8 – 103.8 – 94.3 –––––

TLP-A200-350-Dxxx4x 3000 – 149.7 – – – 118.8 – 103.8 – 94.3 –––––

TLP-A200-450-Dxxx4x 3000 – 158.8 – – – 126.1 – 110.1 – 100.1 –––––

TLP-A200-550-Dxxx4x 3000 – 154.8 – – – 122.9 – 107.3 – 97.5 –––––

TLP-A200-750-Dxxx4x 2500 – 163.3 – – – 129.6 – 113.2 – 102.9 –––––

TLP-A235-11K-Dxxx4x 2000 458.3 – 363.8 – – 317.8 288.7 – – – –––––

TLP-A235-15K-Dxxx4x 2000 478.8–380––332301.6––––––––

Axial Load Force Ratings (zero radial load) for Non-brake Motors (continued)
