Rockwell Automation Publication TLP-IN001A-EN-P - October 2019 13
Kinetix TLP Servo Motors with 046…235 mm Frame Size
Axial Load Force Ratings (maximum radial load) for Brake Motors
Motor Cat. No.
(1)
(1) 1.0 kgf = 2.2 lbf or 9.8 N.
Speed, max
rpm
RPM
500
kgf
750
kgf
1000
kgf
1125
kgf
1250
kgf
1500
kgf
2000
kgf
2250
kgf
2500
kgf
3000
kgf
3375
kgf
3750
kgf
4500
kgf
5000
kgf
6000
kgf
TLP-A046-005-Dxxx4x 6000 –––––6.7–––5 ––4.2–3.7
TLP-A046-010-Dxxx4x 6000 –––––6.9–––5.1––4.3–3.8
TLP-A070-020-Dxxx4x 6000 –––––11.7–––8.7––7.3–6.4
TLP-A070-040-Dxxx4x 6000 –––––12.3–––9.1––7.6–6.7
TLP-A090-075-Dxxx4x 6000 –––––15.3–––11.3––9.5–8.4
TLP-A100-100-Dxxx4x 3000 –20.1–––14.9–12.5–11–––––
TLP-A115-100-Dxxx4x 5000 – – – – 20.3 – – – 15 – – 12.6 – 11.1 –
TLP-A115-200-Dxxx4x 5000 – – – – 21.5 – – – 15.9 – – 13.3 – 11.8 –
TLP-A145-050-Dxxx4x 3000 –34.2–––25.3–21.2–18.7–––––
TLP-A145-090-Dxxx4x 2000 42.9–31.8––26.623.5––––––––
TLP-A145-100-Dxxx4x 3000 –34.2–––25.3–21.2–18.7–––––
TLP-A145-150-Dxxx4x 3000 –36–––26.6–22.3–19.7–––––
TLP-A200-200-Dxxx4x 3000 –60.9–––45.1–37.8–33.4–––––
TLP-A200-300-Dxxx4
x 2500 –65.3–––48.3–40.5–35.8–––––
TLP-A200-350-Dxxx4x 3000 –65.3–––48.3–40.5–35.8–––––
TLP-A200-450-Dxxx4x 3000 –69.6–––51.5–43.2–38.1–––––
TLP-A200-550-Dxxx4x 3000 –67.7–––50.1–42–37.1–––––
TLP-A200-750-Dxxx4x 2500 –71.7–––53.1–44.5–39.3–––––
TLP-A235-11K-Dxxx4x 2000 75.5–55.9––46.841.3––––––––
TLP-A235-15K-Dxxx4x 2000 85–62.9––52.846.6––––––––
