Exercise 1: Using the HIM Keypad and Display
In this section you will perform the following:
• Review key information about the HIM keypad and display of the PowerFlex 525
• Reset the PowerFlex 525 drive to defaults
• Configure several parameters
Information
The PowerFlex 525 is easy to configure with flexibility in programming options to meet your application. One of which is the
Liquid Crystal Display (LCD) Human Interface Module (HIM). Some of its key features are as follows:
• Improved visibility
• Increased resolution
• Descriptive scrolling text
o Three adjustable speeds
• Full Alphanumeric with 5 Digits and 16 Segments
Page 6 of 64
