20 Rockwell Automation Publication 750-RM100A-EN-P - August 2019
Chapter 2 AC Line Tuning
Frames 10…15 have multiple LCL filter modules. The first filter module can be
used as a guide to de-tune all filter modules in the product. However, it is
recommended that you check the other modules to make sure that their currents
are below their respective threshold. Table 6
shows the parameter numbers and
Table 4 - Capacitor Resonance Fault Thresholds—400/480V Products
Frame 400V ND Rating Codes
(1)
(1) Catalog number positions 7…10.
480V ND Rating Codes
(1)
Resonance Current [A]
Alarm Fault
5 C015…C043 D014…D040 3 4
C060…C104 D052…D096 6 7
6 C140, C176 D125, D156 11 14
C205, C260 D186, D248 18 23
7 C302…C585 D302…D617 23 31
8 C302…C540 D302…D505 23 31
C585…C770 D545…D740 31 41
9 C920, C1K0 D800, D960 46 62
C1K1…C1K4 D1K0…D1K3 62 82
10 C1K6…C2K1 D1K4…D2K0 62 82
11 C2K8 D2K6 62 82
12 C3K5 D3K4 62 82
13 C4K2 D4K0 62 82
14 C5K6 D5K4 62 82
15 C7K0 D6K7 62 82
Table 5 - Capacitor Resonance Fault Thresholds—600/690V Products
Frame 600V ND Rating Codes
(1)
(1) Catalog number positions 7…10.
690V ND Rating Codes
(1)
Resonance Current [A]
Alarm Fault
5 E011…E062 F015…F061 5 6
6 E077…E144 F082…F142 10 13
7 E192…E395 F171…F370 23 31
8 E242…E545 F215…F505 23 31
9 E595…E760 F565…F735 31 41
E825, E980 F820, F920 46 62
10 E1K1…E1K5 F1K0…F1K4 46 62
11 E2K0 F1K8 46 62
12 E2K4 F2K3 46 62
13 E2K9 F2K7 46 62
14 E3K9 F3K6 46 62
15 E4K9 F4K5 46 62
