4 Rockwell Automation Publication 750-IN017B-EN-P - June 2018
PowerFlex 750-Series Service Cart Frames 8…10 Conversion Kit
Illustration Conventions
The following visual conventions are used in the IP00 kit installation illustrations.
Convention Description Convention Description Convention Description
Step number. Force application direction Areas that have eye
hazards are identified in
these instructions by this
image. Take precautions
when you install or remove
assemblies that are
identified as sensitive.
Number of times the step is
performed.
Part/assembly placement
ATTENTION: To avoid personal injury or equipment damage, only qualified personnel familiar with
adjustable frequency AC drives, and their equipment, can plan or implement installation, startup, and
subsequent maintenance of the system.
ATTENTION: To avoid dismemberment or personal injury, review all product labels and the potential pinch
point hazards before you assemble or use the service accessories. Do not place yourself near pinch points
during assembly or use.
ATTENTION: To guard against death, serious personal injury, or equipment damage, do not subject the
power module to high rates of acceleration or deceleration while transporting. Power modules have a high
center of gravity. Do not push or pull above the points that are indicated on the power module.
This label, affixed to
the power module
chassis, identifies the
center of gravity.
Renewal Part Availability
Description Cat. No.
PowerFlex 750-Series frame
8…10 conversion plate safety
clips
SK-R1-CARTCLIP
