Rockwell Automation Publication PFLEX-AP005A-EN-P - October 2010 9
Drive Selection Considerations Chapter 1
Table 2 - PowerFlex Drive Comparisons (continued)
PowerFlex Drive
700 Standard Cassette
700 Vector Cassette
Series B 753 755
Environmental Ratings
Enclosure types and ambient temperature range:
IP20, NEMA/UL Type Open 0 to 50 °C (32 to 122 °F)
(1)
0 to 40 °C (32 to 104 °F)
(2)
0 to 65 °C (32 to 149 °F)
(3)
0 to 50 °C (32 to 122 °F)
(1)
0 to 40 °C (32 to 104 °F)
(2)
0 to 65 °C (32 to 149 °F)
(3)
0 to 50 °C (32 to 122 °F)
(5)
0 to 50 °C (32 to 122 °F)
(5)
IP00, NEMA/UL Type Open N/A N/A 0 to 50 °C (32 to 122 °F)
(6)
0 to 50 °C (32 to 122 °F)
(6)
IP20, NEMA/UL Type 1 (w/hood)
N/A N/A 0 to 40 °C (32 to 104 °F)
(5)
0 to 40 °C (32 to 104 °F)
(5)
IP20, NEMA/UL Type 1 (w/label)
N/A N/A 0 to 40 °C (32 to 104 °F)
(6)
0 to 40 °C (32 to 104 °F)
(6)
IP20, NEMA/UL Type 1
(MCC cabinet)
N/A N/A N/A 0 to 40 °C (32 to 104 °F)
(9)
Flange enclosure types and ambient temperature range:
Front
IP20, NEMA/UL, Type Open
IP00, NEMA/UL, Type Open
N/A
N/A
N/A
N/A
0 to 50 °C (32 to 122 °F)
(5)
0 to 40 °C (32 to 104 °F)
(6)
0 to 50 °C (32 to 122 °F)
(5)
0 to 40 °C (32 to 104 °F)
(6)
Back/heatsink
IP20, NEMA/UL, Type Open
IP66, NEMA/UL, Type 4X
0 to 40 °C (32 to 104 °F)
(2)
N/A
0 to 40 °C (32 to 104 °F)
(2)
N/A
N/A
0 to 40 °C (32 to 104 °F)
(7)
N/A
0 to 40 °C (32 to 104 °F)
(7)
Stand-alone/wall mount
IP54, NEMA/UL Type 12 N/A N/A 0 to 40 °C (32 to 104 °F)
(7)
0 to 40 °C (32 to 104 °F)
(7)
Storage temperature range -40 to 70 °C (-40 to 158 °F) -40 to 70 °C (-40 to 158 °F) -40 to 70 °C (-40 to 158 °F) -40 to 70 °C (-40 to 158 °F)
Standards and Certifications
UL YesYesYesYes
CE YesYesYesYes
CSA YesYesYesYes
C-Tick YesYesYesYes
ATEX Yes Yes N/A N/A
RINA Yes Yes
(1)
N/A N/A
TUV-FS No No Yes Yes
ROHS No No Yes Yes
Protection
Motor overload Standard Standard Standard Standard
Output short circuit Standard Standard Standard Standard
Output ground fault Standard Standard Standard Standard
Under and over voltage Standard Standard Standard Standard
Dynamic braking Internal chopper
(4)
Internal chopper
(4)
Internal chopper
(8)
Internal chopper
(8)
Common mode choke Internal (standard) Internal (standard)
(1)
External (optional) External (optional)
(1) Frames 0…6 only.
(2) Frames 7…10 only; applies to chassis (heatsink).
(3) Frames 7…10 only; applies to control (front of backplane).
(4) Standard on Frames 0…3 and optional on Frames 4…6.
(5) Frames 2…5 only.
(6) Frames 6 and 7 only.
(7) Frames 2…7 only.
(8) Standard on Frames 2…5 and optional on Frames 6…7.
(9) Frame 8 only.
