Rockwell Automation FlexPak 3000 OIM User Manual

Using Quick Start
5-11
PULSE TACH QUADRATURE
(P.208)
Only available if
FEEDBACK SELECT
is
set to
PULSE TACH
.
Parameter Range:
ON
OFF
Default Setting:
ON
Parameter Type:
Configurable
Enables or disables pulse encoder quadrature.
A quadrature pulse encoder must be used on regenerative drives that use a pulse
encoder.
Set
ON
for a bidirectional pulse encoder.
Set
OFF
for a unidirectional pulse encoder.
If
PULSE TACH QUADRATURE
is set to
OFF
and
PULSE TACH
is the selected
FEEDBACK
SELECT
type,
NEGATIVE CURRENT LIM
(P.006) will be set to 0 and
REVERSE DISABLE
(P.015) set to
ON
(preventing reverse direction).
ACCELERATION TIME
(P.001)
Sets the minimum
time that the selected
speed reference can
changed from zero to
TOP SPEED
(P.011).
Parameter Range:
0.1 to 300.0 seconds
Default Setting:
5.0 seconds
Parameter Type:
Tunabl e
If
TRIM MODE SELECT
(P.110) is set to
PROPORTIONAL
, the actual time to accelerate
might be modified by
DRAW PERCENTAGE OUT
(P.196). See the software manual for
information on trim.
DECELERATION TIME
(P.002)
Sets the minimum
time in which the
selected speed
reference can change
from
TOP SPEED
(P.011) to 0.
Parameter Range:
0.1 to 300.0 seconds
Default Setting:
5.0 seconds
Parameter Type:
Tunabl e
If
TRIM MODE SELECT
(P.110) is set to
PROPORTIONAL
, the actual time to decelerate
might be modified by
DRAW PERCENTAGE OUT
(P.196). See the software manual for
information on trim.
