Rockwell Automation FlexPak 3000 OIM User Manual

A-2
FlexPak 3000 DC Drive OIM User’s Guide
DECELERATION TIME
(P.002)
MINIMUM SPEED
(P.003)
MAXIMUM SPEED
(P.004)
JOG ACCEL
/
DECEL TIME
(P.013)
JOG SPEED
(P.012)
POSITIVE CURRENT LIM
(P.005)
NEGATIVE CURRENT LIM
(P.006)
IR COMPENSATION
(P.206)
J
11
ANLG TACH VLT SCL
(P.792)
J
14
ANLG TACH VLT RNG
(P.793)
J
18
ARM I FB RESISTOR
(P.395)
Self Tune
Drive Reference
Drive Reference Test Points
ANALOG AUTO REFERENCE
(P.188)
ANALOG MAN REFERENCE
(P.192)
ANALOG MAN TRIM REF
(P.194)
SPD SOURCE SELECT OUT
(P.193)
DRAW PERCENTAGE OUT
(P.196)
TRIM OUTPUT
(P.197)
SPEED RAMP INPUT TP
(P.198)
SPEED RAMP OUTPUT
(P.199)
JOG RAMP OUTPUT
(P.294)
SPD LOOP REFERENCE
(P.295)
MOP OUTPUT
(P.191)
Drive Reference Trim
TRIM REF REGISTER
(P.107)
TRIM REFERENCE SELECT
(P.108)
TRIM RANGE
(P.109)
TRIM MODE SELECT
(P.110)
