Rockwell Automation FlexPak 3000 OIM

OIM Menu Structure
A-3
Drive Reference Limits
TOP SPEED
(P.011)
MAXIMUM SPEED
(P.004)
MINIMUM SPEED
(P.003)
REVERSE DISABLE
(P.015)
AUTO MODE MIN BYPASS
(P.111)
Drive Reference Ramp
ACCELERATION TIME
(P.001)
DECELERATION TIME
(P.002)
S
-
CURVE ROUNDING
(P.014)
JOG ACCEL
/
DECEL TIME
(P.013)
AUTO MODE RAMP BYPASS
(P.112)
MOP ACCEL TIME
(P.115)
MOP DECEL TIME
(P.120)
Drive Reference Configure
JOG SPEED
(P.012)
ANLG AUTO SIGNAL TYPE
(P.100)
STOP MODE SELECT
(P.114)
STOP SPEED THRESHOLD
(P.113)
AUTO REFERENCE SELECT
(P.103)
MANUAL REF SELECT
(P.106)
JOG OFF DELAY TIME
(P.121)
PRESET SPEED
1 (P.117)
PRESET SPEED
2 (P.118)
PRESET SPEED
3 (P.119)
MOP RESET ENABLE
(P.116)
Drive Reference Scaling
ANLG AUTO ZERO ADJ
(P.102)
ANLG AUTO GAIN ADJ
(P.101)
ANALOG AUTO REFERENCE
(P.188)
ANLG MAN REF ZERO ADJ
(P.105)
