C-2 VSM500 DeviceNet Option Board
C.2 Class Code 0x01 – Identity Object
Class Attributes
Instance 1 Attributes Drive Instance
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 1
2 Get Max Instance UINT 2
3 Get Number of Instances UINT 2
6 Get Max ID Class UINT 7
7 Get Max ID Instance UINT 7
Number of Instances: 2
Attribute ID
Access
Rule Name Data Type Value
1 Get Vendor ID UINT 5
2 Get Device Type UINT 2
3 Get Product Code UINT See Product Codes in Appendix B
4 Get Revision
Major Revision
Minor Revision
Structure of
USINT
USINT
3
2
5 Get Status WORD Bit 0 = Owned
Bit 2 = Configured
Bit 10 = Recoverable Fault
Bit 11 = Unrecoverable Fault
6 Get Serial Number UDINT Unique 32 bit number
7 Get Product Name
String Length
ASCII String
Structure of
USINT
STRING
32
See Product Codes in Appendix B
9 Get Configuration
Consistency Value
UINT Checksum
