DeviceNet Objects
C-3
Instance 2 Attributes: DeviceNet Option Instance
Common Services
Attribute
ID Access Rule Name Data Type Value
1 Get Vendor ID UINT 5
2 Get Device Type UINT 12
3 Get Product Code UINT 75
4 Get Revision
Major Revision
Minor Revision
Structure of
USINT
USINT
1
7
5 Get Status WORD Bit 0 = Owned
Bit 2 = Configured
Bit 10 = Recoverable Fault
Bit 11 = Unrecoverable Fault
6 Get Serial Number UDINT Unique 32 bit number
7 Get Product Name
String Length
ASCII String
Structure of
USINT
STRING
29
“VSM500 DeviceNet Interface”
Service Code
Implemented for
Service NameClass Instance
0x05 No Yes Reset
0x0E Yes Yes Get_Attribute_Single
0x11 Yes No Find_Next_Object_Instance
