C-4 VSM500 DeviceNet Option Board
C.3 Class Code 0x02 – Message Router Object
Class Attributes
Instance Attributes
Common Services
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 1
6 Get Max ID Class UINT 7
7 Get Max ID Instance UINT 4
Attribute ID Access Rule Name Data Type Value
2 Get Number Available UINT 8
3 Get Number Active UINT Number of connections
currently used by system
components
4GetActive
Connections
Array of:
UINT
A list of the connection IDs
of the currently active
connections
Service Code
Implemented for
Service NameClass Instance
0x0E Yes Yes Get_Attribute_Single
