44
Digital centre
2.8 Connection of a programming and read-out track
Warning: Only one loco can be read out
and/or programmed at the same time.
LAN R-BUS B-BUS
DC
Power
Track
Out
Insert
programming track
Disconnect main track
Provided that only one locomotive is located on your installation, you can program it directly on
the main track.
Otherwise, we recommend connecting a separate programming track to the track output.
