RC841U 4K Video Conference PTZ Camera User Manual
7
5 GUI Settings
5.1 MENU
Press [MENU] key to display the main menu. Use
the arrow key to move the cursor to desired item
and press the [HOME] key to confirm to enter the
corresponding sub-menu.
MENU
Exposure
Color
P/T/Z
Noise Reduction
Setup
Communication Setup
AI Mode
Restore Default
[HOME] Enter
[MENU] Exit
5.2 EXPOSURE
When in main menu page, move the cursor to
[Exposure] and press [HOME] key to confirm to
enter the Exposure page as below.
EXPOSURE
Mode Auto
ExpCompMode Of
f
Backlight Of
f
Gain Limit 4
Anti-Flicker 50Hz
Meter Average
DRC 0
Select Change
[MENU] Back
Mode: Auto, Manual, SAE, AAE, Bright.
ExpCompMode (Exposure Compensation Mode):
On, Off (Effective in Auto mode).
ExpComp (Exposure Compensation Value):
-7~+7 (Effective in ExpCompMode On).
Backlight: On, Off (Effective in Auto mode).
Bright: 0~17 (Effective in Bright mode).
Gain Limit: 0~15 (Effective in Auto, SAE, AAE,
Bright mode).
Anti-Flicker: Off, 50Hz, 60Hz (Effective in Auto,
AAE, Bright mode).
Meter: Average, Center, Smart, Top (Effective in
Auto, SAE, AAE, Bright mode).
Iris: F1.8, F2.0, F2.4, F2.8, F3.4, F4.0, F4.8, F5.6,
F6.8, F8.0, F9.6, F11.0, Close (Effective in Manual,
AAE mode).
Shutter: 1/30, 1/50, 1/60, 1/100, 1/125, 1/180,
1/250, 1/350, 1/500, 1/725, 1/1000, 1/1500,
1/2000, 1/3000, 1/4000, 1/6000, 1/10000 (Effective
in Manual, SAE mode).
Gain: 0~7 (Effective in Manual mode).
DRC: 0~8.
5.3 COLOR
When in main menu page, move the cursor to
[Color] and press [HOME] key to confirm to enter
the Color page as below.
COLOR
WB Mode Auto
RG Tuning +1
BG Tuning 0
Saturation 100%
Hue 7
AWB Sens Low
Select Change
[MENU] Back
WB-Mode (White Balance Mode): Auto, Indoor,
Outdoor, One Push, Manual, VAR.
RG Tuning (Red Gain Tuning): -10~+10 (Effective
in Auto, One Push, VAR mode).
BG Tuning (Blue Gain Tuning): -10~+10 (Effective
in Auto, One Push, VAR mode).
Saturation: 60%~200%.
Hue: 0~14.
AWB Sens (The White Balance Sensitivity): Low,
Middle, High (Effective in Auto, One Push mode).
RG (Red Gain): 0~255 (Effective in Manual mode).
BG (Blue Gain): 0~255 (Effective in Manual mode).
Color Temp: 2500K~8000K (Effective in VAR mode).
