RC841U 4K Video Conference PTZ Camera User Manual
2
2) Connect the power adapter to the power
connector on the rear panel of the camera.
The power indicator on the front panel of the
camera turns on.
3) After the camera is powered on, it starts to
initialize, right up to the limit position, and
then both horizontal and vertical go to the
middle position. When the motor stops
running, it indicates the initialization is
completed.
4 About Product
4.1 Features
Full Featured USB Interface
Full featured USB Type-C interface, compatible
with USB3.0 and USB2.0, support audio and
encoding output, support UVC 1.1~1.5 protocol.
4K UHD
The new 1/2.8-inch high-quality UHD CMOS
sensor with a maximum of 8.51 million pixels
enables high-quality images with ultra-high
resolution of 4K (3840x2160). And backward
compatible with 1080P, 720P and other
resolutions.
HDMI 1.4b
Support HDMI 1.4b specification, can directly
output uncompressed 4K raw video.
80.8° Wide-angle Lens + 16x Digital Zoom
Exclusive customized high-quality true 8 million
ultra-high-resolution ultra-wide-angle lens,
horizontal field of view up to 80.8°, optical zoom
up to 12x, and support 16x digital zoom.
Low Illumination
The new CMOS image sensor with ultra-high SNR
can effectively reduce the image noise under low
illumination. The application of 2D and 3D noise
reduction algorithm greatly reduces the image
noise even under the condition of ultra-low
illumination, it keeps the picture clean and clear,
and the SNR of image is as high as 55dB.
PoE
The wired network supports PoE power supply,
the control, power supply, video and audio can
be completed with only a network cable.
Remote Control
The camera can be controlled remotely through
the RS232 serial port, network and USB.
H.264 Slice/H.264 SVC Encoding
The output H.264 code stream supports Slice and
SVC encoding modes to accommodate high-end
USB conference video applications.
Dual Code Stream
Supports two code stream outputs (YUY2, MJPEG,
H.264, any two) to reduce the pressure of host
encoding and decoding.
Multiple and Perfect Interface
Support 4K video output via HDMI, USB 3.0 and
network interface simultaneously.
4.2 Product Specifications
Camera
Signal System
4K30, 4K25, 1080P30,
1080P25
Sensor
1/2.8-inch, CMOS,
Effective Pixel: 8.51M
Scanning Mode Progressive
Lens
12x,
f=3.47mm~41.65mm,
F 1.84~F 3.72
Minimum
Illumination
0.5 Lux @ (F1.8, AGC ON)
Shutter 1/30s~1/10000s
White Balance
Auto, Indoor, Outdoor,
One Push, Manual, VAR
Backlight
Compensation
Support
Digital Noise
Reduction
2D&3D Digital Noise
Reduction
SNR ≥55dB
Horizontal FOV 80.8°~7.5°
Vertical FOV 49.9°~4.3°
Pan Angle ±170°
