RC841U 4K Video Conference PTZ Camera User Manual
3
Tilt Angle -30°~+90°
Pan Speed 2.7°~35.7°/s
Tilt Speed 2.7°~31.5°/s
Image Flip Support
Image Freeze Support
Preset Position 255
Preset Accuracy 0.1°
USB Features
Operate System
Windows 7/8/10,
Mac OS X, Linux,
Android
Color System/
Compression
YUY2/MJPEG/H.264
Video Format
YUY2 (ISOC):
1080P30 (max.)
MJPEG: 2160P30
(max.)
H.264 AVC: 2160P30
(max.)
H.264 SVC: 2160P30
(max.)
USB Audio
Support
USB Protocol UVC 1.1~1.5
UVC PTZ Support
Network Features
Encode Protocol H.265/ H.264/MJPEG
Video Stream
First Stream,
Second Stream
First Stream
Resolution
3840x2160, 1920x1080,
1280x720, 1024x576,
960x540, 640x480,
640x360
Second Stream
Resolution
640x360, 480x272,
320x240, 320x180
Video Bit Rate for
First Stream
32Kbps~20480Kbps
Video Bit Rate for
Second Stream
32Kbps~6144Kbps
Bit Rate Control CBR, VBR
Frame Rate
50Hz: 1fps~25fps,
60Hz: 1fps~30fps
Audio Type AAC
Audio Bit Rate 96K, 128K, 256K
Protocol
TCP/IP, HTTP, RTSP,
RTMP/RTMP(S), ONVIF,
DHCP, Multicast, etc.
Interfaces
USB Interface 1 x USB 3.0: Type-C
Video Interface 1 x HDMI 1.4b
Network Interface
1 x NET: 10M/100M
Adaptive Ethernet Ports
Audio Interface
1 x LINE IN: 3.5mm
Audio Interface
Communication
Interface
1 x RS232: 8pin Min DIN,
Max. Distance: 30m,
Protocol: VISCA/
Pelco-D/Pelco-P
Power Interface JEITA type (DC 12V)
General Specifications
Input Voltage DC 12V /PoE (802.3af)
Input Current 1.0A
Operating
Temperature
0°C~40°C
Storage
Temperature
-40°C~60°C
Power
Consumption
12W
Dimension (mm) 142.2 x 151.9 x 177.3
Net Weight About 1.6Kg
Product specifications are subject to change
without notice.
