To define the default position of results
1.
Press the [DISPLAY] key on the front panel.
2. In the "Display" dialog box, select the "Diagram Layout" tab.
3. Under "Result box", select the "Default position":
● "Preview": result icon on the signal bar
● "Floating": floating result box in front of the diagrams
4. For result boxes of automatic measurements, the docked position is the
default. In docked position, the result table is placed below the diagram. To
change the default position of measurement results, select "Meas" menu >
"Gate/Display" > "Default" position.
To adjust the font size in result boxes
1. Press the [SETUP] key.
2. Select the "Screen" tab.
3. Set the "Result dialog font size".
6.9 Using Dialog Boxes
All functionality is provided in dialog boxes as known from computer programs.
You can control the instrument intuitively with the touchscreen. This section pro-
vides an overview of the accessing methods and describes how to use the dialog
boxes.
Each dialog box has four icons in the upper right corner:
Go back: opens the previously opened dialog box.
Go forward: opens the next dialog box.
Minimizes the dialog box to a small box that only contains the last selected func-
tion.
Closes the dialog box.
Using Dialog Boxes
