Instrument Tour
R&S
®
RTP
22Getting Started 1337.9946.02 ─ 05
Probe Compensation
Probe compensation terminal to support adjustment of passive probes to the
oscilloscope channel.
Protective earth conductor for grounding the instrument.
Square wave signal for probe compensation, 1 kHz and 1 V
pp
.
Ground connector for probes.
USB
Two USB type A connectors that comply with standard USB 3.0. They are used to
connect devices like keyboard, mouse, printer and USB flash drive.
Note: Electromagnetic interference (EMI) can affect the measurement results. To
avoid any impact, do not use USB connecting cables exceeding 1 m.
Mixed signal option R&S RTP-B1 / digital extension port R&S RTP-B1E
The mixed signal option R&S RTP-B1 provides logic analizer functionality and 16
digital channels. It also can connect the R&S RT-ZVC multi-channel power probe.
The connectors can be used to connect two logical probes with 8 digital channels
each (D0 to D7 and D8 to D15), or two flat interface cables of R&S RT-ZVC.
The digital extension port R&S RTP-B1E provides the connectors for the
R&S RT-ZVC multi-channel power probe without MSO. The connectors can be
used to connect two flat interface cables of R&S RT-ZVC.
One of the options can be installed in one of option slots at the front panel, or in
the option slot at the rear panel.
The maximum input voltage is 40 V peak at 100 kΩ input impedance. The maxi-
mum input frequency for a signal with the minimum input voltage swing of 500 mV
(V
pp
) is 400 MHz. For detailed specifications, refer to the data sheet.
Waveform generator option R&S RTP-B6
The waveform generator can generate various function and arbitrary waveforms,
sweeps, and parallel patterns. For detailed specifications, refer to the data sheet.
The option can be installed in one of option slots at the front panel.
The module provides the following connectors:
[Gen1, Gen2] BNC connectors
[PattGen] Connector for the pattern generator
