Length correction
Avoids wrong weft length measurement due to the eventual
overlapping of the coils on
the Spool body.
• Possible setting:
ON / OFF
• Recommended setting:
ON
Note:
Set OFF in case of short picks (one coil less)
with
irregular insertion times.
Double yarn sensor
Controls the yarn break by means of an external
sensor (Roj PIEZO sensor TFE6).
• Possible setting:
ON / OFF
Rotation direction
To set the winding direction of the Feeder according to the yarn twist.
• Possible setting:
Z / S
Note:
When changing the winding direction, the coils pitch has to be
changed too.
Maintenance
Calibrate hardware
Not used with Super Elf X3
Stopper / Pulsar test
This test activates a test cycle on the pulsar that will
move the pulsar fork according to the settings in the
Filling tensioner menu. The Stopper
electromagnet is
also activated.
Check reserve sensor
Not used with Super Elf X3
