ROJ SUPER ELF X3 - Reserve Windings; Filling Tensioner (Pulsar HP); Stroke

SUPER ELF X3
–
Dornier
11
Off
-
Automatic position control deactivated
0
-
Autom
atic position control activated
with lower reserv
e storage
1
-
Autom
atic position control activated
with standard reserve storage
2
-
Autom
atic position control activated
with maximum reserve storage
(the take
-
off point is
nearby the stopper pin)
• Recommended setting:
1
Reserve windings
(to be set when Automatic = OFF)
It sets the number of coils to be wound on Spool body when a new Reserve is loaded.
Set the
highest number of coils possible, avoiding them to overlap each other nearby the stopper pin
(t
he reserve has to be over 3/4 of t
he
spool body
length
)
.
• Possible setting:
12
-
> 68.
• Recommended setting: according to the yarn co
unt, set the coils pitch as low
as possible.
Note:
In case of different reserve position between Feeders, set with the same number of
coils
and make them
equal by adjusting the coils pitch.
Filling Tensioner (Pulsar HP)
Stroke
This parameter allows
set
the stroke angle value:
• Possible setting:
off
brake disabled
1
minimum stroke angle
2
low stroke angle
3
middle stroke angle
4
high stroke angle
5
maximum stroke angle
Set here the Yarn type
Possible settings:

fiber

filament < 500dTex

wool

filament > 500dTex
The Pulsar HP will automaticall
y use
the factory
pre
-
settings according to
the chosen yarn
type
