8
3-2 DIP Switch Settings
DIP switches settings must be made only when the power is turned off.
NOTICE
8
7
6
5
4
3
2
1
OFF ON
10
9
- All DIP switches are set to OFF when shipped from the factory.
- When SW-2 is set to OFF, SW-3 may be set to either ON or OFF.
- When SW-8 has been set to ON (heavy), cutting speed is limited to the range of 10 to 100 mm/sec. At this time, operation never
exceeds 100 mm/sec., even is an instruction for a speed greater than 100 mm/sec. is received from the computer.
SW-1—5 : Sets the communication parameters for a serial connection. When the CM-24/12 is connected to the computer through
the serial port, be sure that the communication parameters for SW-1 to SW-6 are set correctly, matching the computer
port settings.
SW-6 : Rotates the text (or graphics) 90 degrees. When set to ON (rotate), the origin point is set at the bottom right of the
material, and the direction of cutting is rotated 90 degrees.
SW-7 : Sets the amount of offset for the cutter blade. Set to OFF when using a tool with a blade offset of 0.25 mm, or to ON
when using a tool with a blade offset of 0.5 mm.
When using the included blade, set to OFF (0.25 mm).
SW-8 : Sets the weight of the material. If material feed is not performed smoothly, set this switch to ON (heavy). When set to
ON, the upper limit for cutting speed is set to 100 mm/sec., and the force used to move the material and the blade
increases. This switch should normally be set to OFF (light).
SW-9 : Sets the size of the material. Set this to ON when using a piece material (piece), and set it to OFF (roll) when using a
rolled material.
SW-10 : Smoothing is a function for cutting smooth circles and arcs. Smoothing is enabled when this switch is set to OFF
(enabled).
DIP switch Function OFF ON
SW-1 Baud rate 9600 4800
SW-2 Parity check Disable Enable
SW-3 Parity check ODD EVEN
SW-4 Data bits 8-bits 7-bits
SW-5 Stop bits 1-bit 2-bits
SW-6 Rotate Do not rotate Rotate
SW-7 Blade offset 0.25 0.5
SW-8 Material weight Light Heavy
SW-9 * Material size Roll Piece
SW-10 Smoothing ON OFF
* On the CM-12, SW-9 is not used. This switch should always be set to "OFF."
