Roland CD-2i

49
Advanced UsesRecording Listening Deleting Creating a CD Editing an SD Appendices
Convenient
Functions
Information
/ Display
Checking /
Preparations
Recording an Electronic Instrument
Here’s how to connect an electronic instrument such as a digital piano or keyboard, and
record your performance.
4
Connect the CD-2i’s LINE/PHONO IN jacks to your electronic instrument
(digital piano, keyboard, etc.).
Use audio cables to connect the CD-2i’s LINE/PHONO IN jacks to the output jacks of
your electronic musical instrument.
fig.connect-piano-e.eps
5
Press the [MENU] button to access the menu screen and select “LINE/
PHONO Input.“
fig.menu-overdub-e.eps
Press the [MENU] button to access the menu screen.
Use the [ ] [ ] buttons to choose “LINE/PHONO
Input.”
Press the [ENTER] button to confirm your choice.
Use the [+] [-] buttons to change the value to select
“LINE.“
* With the factory settings, this is set to Line.
If you’re Recording to an SD
Memory Card
If you’re Recording to a
CD-R/RW Disc
1 Turn on the power ( ☞ Page 21, 23) . 1 Turn on the power ( ☞ Page 21) .
2
Insert the SD memory card
( ☞ Page 25).
2
Insert the CD ( ☞ Page 28).
3 Set the audio source to “SD.”
Press the [SD CARD] button so it’s lit.
fig.selectCD-e.eps
3 Set the audio source to “CD.”
Press the [CD] button so it’s lit.
fig.selectSD-e.eps
CD-2i: RCA phono type
Electronic musical instrument: RCA phono type or phone type
Types of plugs that can be connected
* Refer to the owner’s manual of your electronic musical instrument for the appropriate
type of plug to use.
To the output jacks of your
electronic musical instrument
RL
