Roland E-09 Service Notes

11
E-09
EXPLODED VIEW 3 PARTS LIST
No PART CODE PART NAME DESCRIPTION Q’TY
d 40011312 SCREW M3X8 BINDING TAPTITE P BZC 32
e 40011301 SCREW M3X6 BINDING P-TITE FE BZC 4
f 40011334 SCREW M3X12 BINDING TAPTITE P FE BZC 12
g 40012490 SCREW M4X10 BINDING TAPTITE P BZC 21

Roland E-09 Specifications

General

Polyphony	64 voices
Display	Custom LCD
Weight	5.5 kg
Power Supply	AC adaptor
Effects	Reverb, Chorus
MIDI	In, Out
Connectors	Output (L/Mono, R), Headphones, MIDI (In, Out), Pedal
Keyboard	61 keys (with velocity)
