Roland E-09 Service Notes

9
E-09
EXPLODED VIEW 2 PARTS LIST
No PART CODE PART NAME DESCRIPTION Q’TY
a 40012956 SCREW M3X8 PAN MACHINE W/SW+PW FE BZC 3
b 40011201 SCREW M3X8 PAN HEAD TAPTITE P BZC 2
c 40011512 SCREW M3X12 PAN MACHINE W/SW BZC 1
d 40011312 SCREW M3X8 BINDING TAPTITE P BZC 56

Roland E-09 Specifications

General

Polyphony	64 voices
Display	Custom LCD
Weight	5.5 kg
Power Supply	AC adaptor
Effects	Reverb, Chorus
MIDI	In, Out
Connectors	Output (L/Mono, R), Headphones, MIDI (In, Out), Pedal
Keyboard	61 keys (with velocity)
