Roland E-09 Service Notes

7
E-09
EXPLODED VIEW PARTS LIST
No PART CODE PART NAME DESCRIPTION Q’TY
1 04122634 MUSIC REST ASSY FOR SERVICE(#04018023+#12359137x2) 1
2 04018545 KEYTOP(ON/OFF) S-BUTTON LX BLK 1
3 04018534 R-KNOB LF BLK 1
4 04018789 SPEAKER COVER L 1
5 04128290 GRILL CLOTH INNER 2
6 04018823 DISPLAY COVER 1
7 04018801 PANEL SHEET L 1
8 04018812 PANEL SHEET R 1
9 04017634 TOP CASE 1
10 22365714 CORD HOOK 1
11 03454690 PUSH SWITCH SDKLA10900 1
12 03234723 BENDER PB-H0204
13 04011312 PHONES BOARD ASSY FOR SERVICE 1
14 03902867 LCD UNIT UCZ24080 1
15 04017956 LCD HOLDER 2
16 04011290 PANEL L BOARD ASSY FOR SERVICE 1
17 04129234 KEYTOP SHEET-L 1
18 04120689 INSULATING SHEET FOR PANEL-L BOARD 1
19 04011301 PANEL R BOARD ASSY FOR SERVICE 1
20 04129245 KEYTOP SHEET-R 1
21 04120690 INSULATING SHEET FOR PANEL-R BOARD 1
22 04011323 MAIN BOARD ASSY FOR SERVICE 1
NOTE:’MAIN BOARD ASSY ‘ includes the following parts.
23 04120667 SHIELD SHEET 1
37 04120678 INSULATING SHEET FOR MAIN BOARD 1
24 03903223 KEYBOARD ASSY FOR SERVICE 1
25 04125312 WOOFER #410100-09330 4OHM 20W 2
26 04128390 SPEAKER CUSHION 2
27 04017667 SPEAKER BOX R 1
28 04232889 FERRITE CORE CUSHION 1
29 04129989 SPEAKER INNER CUSHION B 4
30 04018790 SPEAKER COVER R 1
31 03894945 REINFORCE BAR 1
32 04017645 BOTTOM CASE 1
33 12359137 RUBBER FOOT SJ-5012BLK 4
34 04017656 SPEAKER BOX L 1
35 04018901 PANEL CUSHION R 1
36 04018890 PANEL CUSHION L 1

Roland E-09 Specifications

General

Polyphony	64 voices
Display	Custom LCD
Weight	5.5 kg
Power Supply	AC adaptor
Effects	Reverb, Chorus
MIDI	In, Out
Connectors	Output (L/Mono, R), Headphones, MIDI (In, Out), Pedal
Keyboard	61 keys (with velocity)
