Exploded View (Fig. A)
fig.bunkaizu-A.eps
A1
A2
A3
A3
A5
A4
No. Part Code Part Name Description Q’ty
A1 5100037545 SW PEDAL FRONT 1
A2 5100037546 SW PEDAL REAR 1
A3 04560712 SUPPORT SPRING (G2177103R0) 2
A4 5100003910 PEDAL FOOT H=7.6 (G2357126R0) 2
A5 5100037544 SW PEDAL ESCUTCHEON 1
