16
Jun. 2014 GP-10
Parts List
fig.-part1-e.eps
Note: The parts marked # are new. (initial parts) The description “Q’ty” means a necessary number of the parts per one product.
Due to one or more of the following reasons, parts with parts code ******** cannot be supplied
as service parts.
• Supply is prohibited due to copyright restrictions.
• It is carried in electronic data on the Roland web site.
• The part is made to order (at current market price).
• It can be replaced with an article on the market. (battery or etc.)
• It is a package or an accessory irrelevant to the function maintenance of the main body.
• A number of circuit boards are grouped together and supplied as a single circuit board (under a different part code).
• Reissuance is restricted.
• It is supplied as an assembled part
(under a different part code).
Safety Precautions:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
CASING
# 5100037968 TOP COVER 1
# 5100037969 BOTTOM COVER 1
KNOB, BUTTON
5100008051 R-KNOB (G2477525R1) 1
5100007869 R-KNOB INDEX G2477526R1 1
03344945 KEYTOP S 1PC(G2477513R0) 7
12499175 BUTTON JSPUE0011A 1
SWITCH
01780101 TACT SWITCH SKQKABD010 7
03344723 TACT SWITCH SKQKAKD010 4
01899989 PUSH SWITCH SPUP19-2N-LB2 1
JACK, EXT TERMINAL
5100006474 3.5MM JACK HTJ-035-10ABZ(F3439911R0) 2
5100001342 6.5MM JACK HTJ-064-12IMP (13449155R1) 4
# 5100034719 6.5MM JACK HTJ-064-22HSPP 1
04908701 ADAPTOR JACK KM02018ABM1P(F3439875R0) 1
00564556 DIN CONNECTOR TCS5093-10-4152 1
5100017587 USB CONNECTOR UBR23-4K5100(F3439933R0) 1
DISPLAY UNIT
5100010065 LCD PE1602MRT-012-I-Q(F5029425R0) 1
PWB ASSY
# 5100037248 MAIN BOARD ASSY 1
# 5100037249 PANEL SHEET ASSY 1
* This unit includes the following parts.
******** PANEL BOARD 1
******** GK BOARD 1
******** EXP BOARD 1
******** ENC BOARD 1
DIODE
05015956 LED BL L-7104SRT (F5229820R0) 3
POTENTIOMETER
01016167 11M/M ROTARY POTENTIOMETER RK11K1140AFG 10KX1 1
5100006350 POTENTIOMETER(F3229188R1) RD901F-40-15F-B50K-00DQ7 1
# 5100037152 ENCODER RE111F-40B3-15F-20P 1
WIRING, CABLE
# 5100037395 WIRING 3P L=55X5X5 P=2.0 1
# 5100037384 WIRING W1 (EXP) 1
# 5100037393 WIRING W2 (PANEL) 2
# 5100037394 WIRING W3 (INPUT) 1
To Next Page
