7
Jun. 2014 GP-10
Exploded View Parts List
Disassembly Procedure
1. Remove all screws e (8) in Plane View (View 4) (p. 10) and detach the
bottom cover.
2. When detaching the VR pedal, remove the bolt k in Exploded View (Fig.
B) (p. 12).
No. Part Code Part Name Description Q’ty
1 5100007869 R-KNOB INDEX G2477526R1 1
2 5100008051 R-KNOB (G2477525R1) 1
3 5100037968 TOP COVER 1
4 5100037970 DISPLAY COVER 1
5 22360712 CORD HOOK 236-712 1
6 5100018071 POWER SW ESCUTCHEON G2207430R1 1
7 12499175 BUTTON JSPUE0011A 1
8 5100037971 DISPLAY CUSHION 1
9 03561356 SHAFT STAY STAY 1
5100037249 PANEL SHEET ASSY
* This unit includes the following parts.
10 ******** EXP BOARD 1
13 ******** ENC BOARD 1
15 ******** PANEL BOARD 1
18 ******** GK BOARD 1
11 5100010065 LCD PE1602MRT-012-I-Q(F5029425R0) 1
12 03344945 KEYTOP S 1PC(G2477513R0) 7
14 5100037401 PCB SPACER LCA35-3 2
16 5100021018 PWB SPACER LBC-08-N2W 2
17 5100037248 MAIN BOARD ASSY 1
19 5100037969 BOTTOM COVER 1
20 03344923 FOOT H=5 (G2357120R0) 4
a 40128923 HEX NUT M7 H5039521R0 2
b 5100003918 JACK NUT M9X12X2 NI RTC(H5039510R0) 6
c 5100003926 PLAIN WASHER 9X13.5X0.5T NI(H5039158R0) 6
To Next Page
