Roland JV-1010 User Manual

37
Changing Sounds from an External MIDI Device
Quick Start
5
Transmit a Program Change message from the external MIDI
device to the JV-1010 (refer to the following table).
The correspondences between MIDI messages transmitted from external
MIDI devices and Rhythm Set Numbers are as shown below.
Rhythm Set Rhythm Set Bank Select Program
Group Number MSB LSB Number
USER 1, 2 80 0 1, 2
PRESET-A 1, 2 81 0 1, 2
PRESET-B 1, 2 81 1 1, 2
PRESET-C 1, 2 81 2 1, 2
PRESET-D 1, 2 81 3 1, 2
PRESET-E 1, 2 81 4 1, 2
Session 1–8 84 0 1–8
WAVE-EXP 1–128 84 2 1–128
WAVE-EXP 129–256 84 3 1–128

Roland JV-1010 Specifications

General

Type	Synthesizer Module
Polyphony	28 voices
Multitimbral	16 parts
MIDI	In, Out, Thru
Effects	Reverb, Chorus, Delay
Expansion Slot	1 SR-JV80 series expansion board
Synthesis Type	PCM
Outputs	Stereo (L/Mono, R)
Sound Engine	JV-1080 Sound Engine
Presets	512
Headphones	1/4 inch stereo jack
Power Supply	DC 9V
Patches	640 patches (user: 128, preset: 512)
