MIDI Implementation
3. Parameter Address Map
1. JV-1010 (Model ID=6AH)
* For addresses marked by a #, the data must be divided into 2 parts for transmission. For example, data with the hexadecimal value ABH would be divided into 0AH and 0BH, and transmitted
in that order.
* Parameter values enclosed in < > are for the JV-1080 / JV-2080 / XP-30 / XP-50 / XP-60 / XP-80, and will be ignored if received by the JV-1010.
+——————————————————————————————————————————————————————————————————————————————+
| Start | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 00 | System 1-1 |
|—————————————+————————————————————————————————————————————————————————————————|
| 01 00 00 00 | Temporary Performance 1-2 |
| 02 00 00 00 | Performance Mode Temporary Patch(part 1) 1-3 |
| 02 01 00 00 | Performance Mode Temporary Patch(part 2) |
| : | |
| 02 08 00 00 | Performance Mode Temporary Patch(part 9) |
| 02 09 00 00 | Temporary Rhythm Setup 1-4 |
| 02 0A 00 00 | Performance Mode Temporary Patch(part 11) 1-3 |
| : | |
| 02 0F 00 00 | Performance Mode Temporary Patch(part 16) |
| 03 00 00 00 | Patch Mode Temporary Patch 1-3 |
|—————————————+————————————————————————————————————————————————————————————————|
| 10 00 00 00 | User Performance USER:01 1-2 |
| 10 01 00 00 | User Performance USER:02 |
| : | |
| 10 1F 00 00 | User Performance USER:32 |
| 10 40 00 00 | User Rhythm Setup USER:1 1-4 |
| 10 41 00 00 | User Rhythm Setup USER:2 |
| 11 00 00 00 | User Patch USER:001 1-3 |
| 11 01 00 00 | User Patch USER:002 |
| : | |
| 11 7F 00 00 | User Patch USER:128 |
+——————————————————————————————————————————————————————————————————————————————+
● 1-1.System
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | System Common 1-1-1 |
| 10 00 | Part 1 Scale Tune 1-1-2 |
| 11 00 | Part 2 Scale Tune |
| : | |
| 1F 00 | Part 16 Scale Tune |
| 20 00 | Patch Mode Scale Tune 1-1-2 |
+——————————————————————————————————————————————————————————————————————————————+
● 1-1-1.System Common
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Size | Description Data (Value) |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0000 00aa | Sound Mode 0 - 2 *1 |
| 00 01 | 0aaa aaaa | Performance Number 0 - 127 *2 | +———————————————————————————————————————————————————————————+
| 00 02 | 0000 00aa | Patch Group Type 0 - 2 *3 -> | | Patch Group | Group Type | Group ID | Number (value) |
| 00 03 | 0aaa aaaa | Patch Group ID 0 - 127 -> | |—————————————+————————————+——————————+—————————————————————|
|# 00 04 | 0000 aaaa | Patch Number 0 - 255 -> | | USER | 0 | 1 | 0 - 127 (001 - 128) |
| | 0000 bbbb | (001 - 256) | | <CARD | 0 | 2 | 0 - 127 (001 - 128)>|
| 00 06 | 0aaa aaaa | Master Tune 0 - 126 *4 | | PR-A | 0 | 3 | 0 - 127 (001 - 128) |
| 00 07 | 0000 000a | Scale Tune Switch 0 - 1 (OFF,ON) | | PR-B | 0 | 4 | 0 - 127 (001 - 128) |
| 00 08 | 0000 000a | EFX Switch 0 - 1 (OFF,ON) | | PR-C | 0 | 5 | 0 - 127 (001 - 128) |
| 00 09 | 0000 000a | Chorus Switch 0 - 1 (OFF,ON) | | PR-D | 0 | 6 | 0 - 127 (001 - 128) |
| 00 0A | 0000 000a | Reverb Switch 0 - 1 (OFF,ON) | | PR-E | 0 | 7 | 0 - 127 (001 - 128) |
| 00 0B | 0000 000a | Patch Remain 0 - 1 (OFF,ON) | | <PCM | 1 | 1 - 127 | 0 - 127 (001 - 128)>|
| 00 0C | 0000 000a | Clock Source 0 - 1 (INT,MIDI) | |XP-A(Session)| 2 | 9 | 0 - 254 (001 - 255) |
| 00 0D | 0000 0aaa | TAP Control Source 0 - 4 *5 | | XP-B | 2 | 1 - 127 | 0 - 255 (001 - 256) |
| 00 0E | 0000 0aaa | Hold Control Source 0 - 4 *5 | +———————————————————————————————————————————————————————————+
| 00 0F | 0000 0aaa | Peak Control Source 0 - 4 *5 |
| 00 10 | 0000 000a | Volume Control Source 0 - 1 *6 |
| 00 11 | 0000 00aa | Aftertouch Source 0 - 2 *7 |
| 00 12 | 0aaa aaaa | System Control Source 1 1 - 97 *8 |
| 00 13 | 0aaa aaaa | System Control Source 2 1 - 97 *8 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 14 | 0000 000a | Receive Program Change 0 - 1 (OFF,ON) |
| 00 15 | 0000 000a | Receive Bank Select 0 - 1 (OFF,ON) |
| 00 16 | 0000 000a | Receive Control Change 0 - 1 (<OFF,ON>) |
| 00 17 | 0000 000a | Receive Modulation 0 - 1 (<OFF,ON>) |
| 00 18 | 0000 000a | Receive Volume 0 - 1 (<OFF,ON>) |
| 00 19 | 0000 000a | Receive Hold-1 0 - 1 (<OFF,ON>) |
| 00 1A | 0000 000a | Receive Pitch Bend 0 - 1 (<OFF,ON>) |
| 00 1B | 0000 000a | Receive Aftertouch 0 - 1 (<OFF,ON>) |
| 00 1C | 000a aaaa | Control Channel 0 - 16 (1 - 16,OFF)|
| 00 1D | 0000 aaaa | Patch Receive Channel 0 - 15 (1 - 16) |
| 00 1E | 0000 000a | Rhythm Edit Source 0 - 1 *9 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 1F | 0000 00aa | Preview Sound Mode 0 - 2 *10 |
| 00 20 | 0aaa aaaa | Preview Note Set 1 0 - 127 (C-1 - G9) |
| 00 21 | 0aaa aaaa | Preview Velocity Set 1 0 - 127 *11 |
| 00 22 | 0aaa aaaa | Preview Note Set 2 0 - 127 (C-1 - G9) |
| 00 23 | 0aaa aaaa | Preview Velocity Set 2 0 - 127 *11 |
| 00 24 | 0aaa aaaa | Preview Note Set 3 0 - 127 (C-1 - G9) |
| 00 25 | 0aaa aaaa | Preview Velocity Set 3 0 - 127 *11 |
| 00 26 | 0aaa aaaa | Preview Note Set 4 0 - 127 (C-1 - G9) |
| 00 27 | 0aaa aaaa | Preview Velocity Set 4 0 - 127 *11 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 28 | 0000 000a | Transmit Program Change 0 - 1 (<OFF,ON>) |
| 00 29 | 0000 000a | Transmit Bank Select 0 - 1 (<OFF,ON>) |
| 00 2A | 000a aaaa | Patch Transmit Channel 0 - 17 *12 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 2B | 0000 000a | Transpose Switch 0 - 1 (<OFF,ON>) |
| 00 2C | 0000 aaaa | Transpose Value 0 - 11 (<-5 - +6>)|
| 00 2D | 0000 0aaa | Octave Shift 0 - 6 (<-3 - +3>)|
| 00 2E | 0aaa aaaa | Keyboard Velocity 0 - 127 *13 |
| 00 2F | 0000 00aa | Keyboard Sens 0 - 2 *14 |
| 00 30 | 0aaa aaaa | Aftertouch Sens 0 - 100 (<0 - 100>)|
| 00 31 | 0aaa aaaa | Pedal(1) Assign 1 - 104 *15 |
| 00 32 | 0000 00aa | Pedal(1) Output Mode 0 - 3 *16 |
