78
MIDI Implementation
|—————————————+———————————+————————————————————————————————————————————————————|
|# 00 2C | 0000 aaaa | Patch Tempo 20 - 250 |
| | 0000 bbbb | |
| 00 2E | 0aaa aaaa | Patch Level 0 - 127 |
| 00 2F | 0aaa aaaa | Patch Pan 0 - 127 (L64 - 63R)|
| 00 30 | 0aaa aaaa | Analog Feel 0 - 127 |
| 00 31 | 0000 aaaa | Bend Range Up 0 - 12 |
| 00 32 | 00aa aaaa | Bend Range Down 0 - 48 (0 - -48) |
| 00 33 | 0000 000a | Key Assign Mode 0 - 1 (POLY,SOLO)|
| 00 34 | 0000 000a | Solo Legato 0 - 1 (OFF,ON) |
| 00 35 | 0000 000a | Portamento Switch 0 - 1 (OFF,ON) |
| 00 36 | 0000 000a | Portamento Mode 0 - 1 *6 |
| 00 37 | 0000 000a | Portamento Type 0 - 1 (RATE,TIME)|
| 00 38 | 0000 000a | Portamento Start 0 - 1 *7 |
| 00 39 | 0aaa aaaa | Portamento Time 0 - 127 |
| 00 3A | 0000 aaaa | Patch Control Source 2 0 - 15 *8 |
| 00 3B | 0000 aaaa | Patch Control Source 3 0 - 15 *8 |
| 00 3C | 0000 00aa | EFX Control Hold/Peak 0 - 2 *9 |
| 00 3D | 0000 00aa | Control 1 Hold/Peak 0 - 2 *9 |
| 00 3E | 0000 00aa | Control 2 Hold/Peak 0 - 2 *9 |
| 00 3F | 0000 00aa | Control 3 Hold/Peak 0 - 2 *9 |
| 00 40 | 0000 000a | Velocity Range Switch 0 - 1 (OFF,ON) |
| 00 41 | 0000 0aaa | Octave Shift 0 - 6 (-3 - +3) |
| 00 42 | 0000 00aa | Stretch Tune Depth 0 - 3 (OFF,1 - 3)|
| 00 43 | 0000 000a | Voice Priority 0 - 1 *10 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 44 | 0000 aaaa | Structure Type 1&2 0 - 9 (1 - 10) |
| 00 45 | 0000 00aa | Booster 1&2 0 - 3 *11 |
| 00 46 | 0000 aaaa | Structure Type 3&4 0 - 9 (1 - 10) |
| 00 47 | 0000 00aa | Booster 3&4 0 - 3 *11 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 48 | 0000 000a | Clock Source 0 - 1 *12 |
| 00 49 | 0aaa aaaa | Patch Category 0 - 127 *13 |
|—————————————+————————————————————————————————————————————————————————————————|
|Total size | 00 00 00 4A |
+——————————————————————————————————————————————————————————————————————————————+
*1 MIX, <DIRECT-1>, <DIRECT-2>
*2 OFF, SYS-CTRL1, SYS-CTRL2, MODULATION, BREATH, FOOT, VOLUME, PAN, EXPRESSION, PITCH BEND, AFTERTOUCH
*3 MIX, REV, MIX+REV
*4 ROOM1, ROOM2, STAGE1, STAGE2, HALL1, HALL2, DELAY, PAN-DLY
*5 200, 250, 315, 400, 500, 630, 800, 1000, 1250, 1600, 2000, 2500, 3150, 4000, 5000, 6300, 8000, BYPASS
*6 NORMAL, LEGATO
*7 PITCH, NOTE
*8 OFF, SYS-CTRL1, SYS-CTRL2, MODULATION, BREATH, FOOT, VOLUME, PAN, EXPRESSION, PITCH BEND, AFTERTOUCH, LFO1, LFO2, VELOCITY, KEYFOLLOW, PLAYMATE
*9 OFF, HOLD, PEAK
*10 LAST, LOUDEST
*11 0, +6, +12, +18
*12 PATCH, SYSTEM
*13 NO ASSIGN, AC.PIANO, EL.PIANO, KEYBOARDS, BELL, MALLET, ORGAN, ACCORDION, HARMONICA, AC.GUITAR, EL.GUITAR, DIST.GUITAR, BASS, SYNTH BASS, STRINGS,
ORCHESTRA, HIT&STAB, WIND, FLUTE, AC.BRASS, SYNTH BRASS, SAX, HARD LEAD, SOFT LEAD, TECHNO SYNTH, PULSATING, SYNTH FX, OTHER SYNTH, BRIGHT PAD,
SOFT PAD, VOX, PLUCKED, ETHNIC, FRETTED, PERCUSSION, SOUND FX, BEAT&GROOVE, DRUMS, COMBINATION (0–38)
● 1-3-2.Patch Tone
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Size | Description Data (Value) |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0000 000a | Tone Switch 0 - 1 (OFF,ON) | +———————————————————————————————————————————————————————————+
| 00 01 | 0000 00aa | Wave Group Type 0 - 2 *1 -> | | Wave Group | Group Type | Group ID | Number (value) |
| 00 02 | 0aaa aaaa | Wave Group ID 0 - 127 -> | |—————————————+————————————+——————————+—————————————————————|
|# 00 03 | 0000 aaaa | Wave Number 0 - 254 -> | | INT-A | 0 | 1 | 0 - 254 (001 - 255) |
| | 0000 bbbb | (001 - 255)| | INT-B | 0 | 2 | 0 - 192 (001 - 193) |
| 00 05 | 0000 00aa | Wave Gain 0 - 3 *2 | | <PCM | 1 | 1 - 127 | 0 - 254 (001 - 255)>|
| 00 06 | 0000 000a | FXM Switch 0 - 1 (OFF,ON) | |XP-A(Session)| 2 | 9 | 0 - 205 (001 - 206) |
| 00 07 | 0000 00aa | FXM Color 0 - 3 (1 - 4) | | XP-B | 2 | 1 - 127 | 0 - 254 (001 - 255) |
| 00 08 | 0000 aaaa | FXM Depth 0 - 15 (1 - 16) | +———————————————————————————————————————————————————————————+
| 00 09 | 0000 0aaa | Tone Delay Mode 0 - 7 *3 |
| 00 0A | 0aaa aaaa | Tone Delay Time 0 - 127 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 0B | 0aaa aaaa | Velocity Cross Fade 0 - 127 |
| 00 0C | 0aaa aaaa | Velocity Range Lower 1 - 127 *4 |
| 00 0D | 0aaa aaaa | Velocity Range Upper 1 - 127 *5 |
| 00 0E | 0aaa aaaa | Keyboard Range Lower 0 - 127 *6 |
| 00 0F | 0aaa aaaa | Keyboard Range Upper 0 - 127 *7 |
| 00 10 | 0000 000a | Redamper Control Switch 0 - 1 (OFF,ON) |
| 00 11 | 0000 000a | Volume Control Switch 0 - 1 (OFF,ON) |
| 00 12 | 0000 000a | Hold-1 Control Switch 0 - 1 (OFF,ON) |
| 00 13 | 0000 000a | Pitch Bend Control Switch 0 - 1 (OFF,ON) |
| 00 14 | 0000 00aa | Pan Control Switch 0 - 2 *8 |
| 00 15 | 000a aaaa | Controller 1 Destination 1 0 - 18 *9 |
| 00 16 | 0aaa aaaa | Controller 1 Depth 1 0 - 126 (-63 - +63)|
| 00 17 | 000a aaaa | Controller 1 Destination 2 0 - 18 *9 |
| 00 18 | 0aaa aaaa | Controller 1 Depth 2 0 - 126 (-63 - +63)|
| 00 19 | 000a aaaa | Controller 1 Destination 3 0 - 18 *9 |
| 00 1A | 0aaa aaaa | Controller 1 Depth 3 0 - 126 (-63 - +63)|
| 00 1B | 000a aaaa | Controller 1 Destination 4 0 - 18 *9 |
| 00 1C | 0aaa aaaa | Controller 1 Depth 4 0 - 126 (-63 - +63)|
| 00 1D | 000a aaaa | Controller 2 Destination 1 0 - 18 *9 |
| 00 1E | 0aaa aaaa | Controller 2 Depth 1 0 - 126 (-63 - +63)|
| 00 1F | 000a aaaa | Controller 2 Destination 2 0 - 18 *9 |
| 00 20 | 0aaa aaaa | Controller 2 Depth 2 0 - 126 (-63 - +63)|
| 00 21 | 000a aaaa | Controller 2 Destination 3 0 - 18 *9 |
| 00 22 | 0aaa aaaa | Controller 2 Depth 3 0 - 126 (-63 - +63)|
| 00 23 | 000a aaaa | Controller 2 Destination 4 0 - 18 *9 |
| 00 24 | 0aaa aaaa | Controller 2 Depth 4 0 - 126 (-63 - +63)|
| 00 25 | 000a aaaa | Controller 3 Destination 1 0 - 18 *9 |
| 00 26 | 0aaa aaaa | Controller 3 Depth 1 0 - 126 (-63 - +63)|
| 00 27 | 000a aaaa | Controller 3 Destination 2 0 - 18 *9 |
| 00 28 | 0aaa aaaa | Controller 3 Depth 2 0 - 126 (-63 - +63)|
| 00 29 | 000a aaaa | Controller 3 Destination 3 0 - 18 *9 |
| 00 2A | 0aaa aaaa | Controller 3 Depth 3 0 - 126 (-63 - +63)|
| 00 2B | 000a aaaa | Controller 3 Destination 4 0 - 18 *9 |
| 00 2C | 0aaa aaaa | Controller 3 Depth 4 0 - 126 (-63 - +63)|
