MIDI Implementation
*16 -100–+150
*17 -100, -70, -50, -40, -30, -20, -10, 0, +10, +20, +30, +40, +50, +70, +100
*18 OFF, LPF, BPF, HPF, PKG
*19 LOWER, UPPER, LOWER&UPPER, ALL
*20 MIX, EFX, <DIRECT-1>, <DIRECT-2>
● 1-4.Rhythm Setup
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | Rhythm Common 1-4-1 |
| 23 00 | Rhythm Note for Key# 35 1-4-2 |
| 24 00 | Rhythm Note for Key# 36 |
| : | |
| 62 00 | Rhythm Note for Key# 98 |
+——————————————————————————————————————————————————————————————————————————————+
● 1-4-1.Rhythm Common
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Size | Description Data (Value) |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0aaa aaaa | Rhythm Name 1 32 - 127 |
| 00 01 | 0aaa aaaa | Rhythm Name 2 32 - 127 |
| 00 02 | 0aaa aaaa | Rhythm Name 3 32 - 127 |
| 00 03 | 0aaa aaaa | Rhythm Name 4 32 - 127 |
| 00 04 | 0aaa aaaa | Rhythm Name 5 32 - 127 |
| 00 05 | 0aaa aaaa | Rhythm Name 6 32 - 127 |
| 00 06 | 0aaa aaaa | Rhythm Name 7 32 - 127 |
| 00 07 | 0aaa aaaa | Rhythm Name 8 32 - 127 |
| 00 08 | 0aaa aaaa | Rhythm Name 9 32 - 127 |
| 00 09 | 0aaa aaaa | Rhythm Name 10 32 - 127 |
| 00 0A | 0aaa aaaa | Rhythm Name 11 32 - 127 |
| 00 0B | 0aaa aaaa | Rhythm Name 12 32 - 127 |
|—————————————+————————————————————————————————————————————————————————————————|
|Total size | 00 00 00 0C |
+——————————————————————————————————————————————————————————————————————————————+
● 1-4-2.Rhythm Note
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Size | Description Data (Value) |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0000 000a | Tone Switch 0 - 1 (OFF,ON) | +———————————————————————————————————————————————————————————+
| 00 01 | 0000 00aa | Wave Group Type 0 - 2 *1 -> | | Wave Group | Group Type | Group ID | Number (value) |
| 00 02 | 0aaa aaaa | Wave Group ID 0 - 127 -> | |—————————————+————————————+——————————+—————————————————————|
|# 00 03 | 0000 aaaa | Wave Number 0 - 254 -> | | INT-A | 0 | 1 | 0 - 254 (001 - 255) |
| | 0000 bbbb | (001 - 255) | | INT-B | 0 | 2 | 0 - 192 (001 - 193) |
| 00 05 | 0000 00aa | Wave Gain 0 - 3 *2 | | <PCM | 1 | 1 - 127 | 0 - 254 (001 - 255)>|
| 00 06 | 0000 aaaa | Bend Range 0 - 12 | |XP-A(Session)| 2 | 9 | 0 - 205 (001 - 206) |
| 00 07 | 000a aaaa | Mute Group 0 - 31 (OFF,1 - 31)| | XP-B | 2 | 1 - 127 | 0 - 254 (001 - 255) |
| 00 08 | 0000 000a | Envelope Mode 0 - 1 *3 | +———————————————————————————————————————————————————————————+
| 00 09 | 0000 000a | Volume Control Switch 0 - 1 (OFF,ON) |
| 00 0A | 0000 000a | Hold-1 Control Switch 0 - 1 (OFF,ON) |
| 00 0B | 0000 00aa | Pan Control Switch 0 - 2 *4 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 0C | 0aaa aaaa | Coarse Tune 0 - 127 (C-1 - G9) |
| 00 0D | 0aaa aaaa | Fine Tune 0 - 100 (-50 - +50)|
| 00 0E | 000a aaaa | Random Pitch Depth 0 - 30 *5 |
| 00 0F | 000a aaaa | Pitch Envelope Depth 0 - 24 (-12 - +12)|
| 00 10 | 0aaa aaaa | Pitch Envelope Velocity Sens 0 - 125 *6 |
| 00 11 | 0000 aaaa | Pitch Envelope Velocity Time 0 - 14 *7 |
| 00 12 | 0aaa aaaa | Pitch Envelope Time 1 0 - 127 |
| 00 13 | 0aaa aaaa | Pitch Envelope Time 2 0 - 127 |
| 00 14 | 0aaa aaaa | Pitch Envelope Time 3 0 - 127 |
| 00 15 | 0aaa aaaa | Pitch Envelope Time 4 0 - 127 |
| 00 16 | 0aaa aaaa | Pitch Envelope Level 1 0 - 126 (-63 - +63)|
| 00 17 | 0aaa aaaa | Pitch Envelope Level 2 0 - 126 (-63 - +63)|
| 00 18 | 0aaa aaaa | Pitch Envelope Level 3 0 - 126 (-63 - +63)|
| 00 19 | 0aaa aaaa | Pitch Envelope Level 4 0 - 126 (-63 - +63)|
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 1A | 0000 0aaa | Filter Type 0 - 4 *8 |
| 00 1B | 0aaa aaaa | Cutoff Frequency 0 - 127 |
| 00 1C | 0aaa aaaa | Resonance 0 - 127 |
| 00 1D | 0aaa aaaa | Resonance Velocity Sens 0 - 125 *6 |
| 00 1E | 0aaa aaaa | Filter Envelope Depth 0 - 126 (-63 - +63)|
| 00 1F | 0aaa aaaa | Filter Envelope Velocity Sens 0 - 125 *6 |
| 00 20 | 0000 aaaa | Filter Envelope Velocity Time 0 - 14 *7 |
| 00 21 | 0aaa aaaa | Filter Envelope Time 1 0 - 127 |
| 00 22 | 0aaa aaaa | Filter Envelope Time 2 0 - 127 |
| 00 23 | 0aaa aaaa | Filter Envelope Time 3 0 - 127 |
| 00 24 | 0aaa aaaa | Filter Envelope Time 4 0 - 127 |
| 00 25 | 0aaa aaaa | Filter Envelope Level 1 0 - 127 |
| 00 26 | 0aaa aaaa | Filter Envelope Level 2 0 - 127 |
| 00 27 | 0aaa aaaa | Filter Envelope Level 3 0 - 127 |
| 00 28 | 0aaa aaaa | Filter Envelope Level 4 0 - 127 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 29 | 0aaa aaaa | Tone Level 0 - 127 |
| 00 2A | 0aaa aaaa | Level Envelope Velocity Sens 0 - 125 *6 |
| 00 2B | 0000 aaaa | Level Envelope Velocity Time 0 - 14 *7 |
| 00 2C | 0aaa aaaa | Level Envelope Time 1 0 - 127 |
| 00 2D | 0aaa aaaa | Level Envelope Time 2 0 - 127 |
| 00 2E | 0aaa aaaa | Level Envelope Time 3 0 - 127 |
| 00 2F | 0aaa aaaa | Level Envelope Time 4 0 - 127 |
| 00 30 | 0aaa aaaa | Level Envelope Level 1 0 - 127 |
| 00 31 | 0aaa aaaa | Level Envelope Level 2 0 - 127 |
| 00 32 | 0aaa aaaa | Level Envelope Level 3 0 - 127 |
| 00 33 | 0aaa aaaa | Tone Pan 0 - 127 (L64 - 63R)|
| 00 34 | 00aa aaaa | Random Pan Depth 0 - 63 |
| 00 35 | 0aaa aaaa | Alternate Pan Depth 1 - 127 (L63 - 63R)|
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 36 | 0000 00aa | Output Assign 0 - 3 *9 |
| 00 37 | 0aaa aaaa | Mix/EFX Send Level 0 - 127 |
| 00 38 | 0aaa aaaa | Chorus Send Level 0 - 127 |
| 00 39 | 0aaa aaaa | Reverb Send Level 0 - 127 |
|—————————————+————————————————————————————————————————————————————————————————|
|Total size | 00 00 00 3A |
+——————————————————————————————————————————————————————————————————————————————+
