82
MIDI Implementation
2. GS (Model ID = 42H)
+—————————————————————————————————————————————————————————————————————————————+
| Start | |
| address | Description |
|—————————————+———————————————————————————————————————————————————————————————|
| 40 10 00 | Scale Tune Part10 2-1 |
| 40 11 00 | : Part1 |
| 40 12 00 | : Part2 |
| 40 13 00 | : Part3 |
| 40 14 00 | : Part4 |
| 40 15 00 | : Part5 |
| 40 16 00 | : Part6 |
| 40 17 00 | : Part7 |
| 40 18 00 | : Part8 |
| 40 19 00 | : Part9 |
| 40 1A 00 | : Part11 |
| 40 1B 00 | : Part12 |
| 40 1C 00 | : Part13 |
| 40 1D 00 | : Part14 |
| 40 1E 00 | : Part15 |
| 40 1F 00 | : Part16 |
+—————————————————————————————————————————————————————————————————————————————+
● 2-1.Scale Tune
+—————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+———————————————————————————————————————————————————————————————|
| 40 | 0aaa aaaa | Scale Tune for C 0 - 127 |
| | | (-64 - +63) |
| 41 | 0aaa aaaa | Scale Tune for C# 0 - 127 |
| | | (-64 - +63) |
| 42 | 0aaa aaaa | Scale Tune for D 0 - 127 |
| | | (-64 - +63) |
| 43 | 0aaa aaaa | Scale Tune for D# 0 - 127 |
| | | (-64 - +63) |
| 44 | 0aaa aaaa | Scale Tune for E 0 - 127 |
| | | (-64 - +63) |
| 45 | 0aaa aaaa | Scale Tune for F 0 - 127 |
| | | (-64 - +63) |
| 46 | 0aaa aaaa | Scale Tune for F# 0 - 127 |
| | | (-64 - +63) |
| 47 | 0aaa aaaa | Scale Tune for G 0 - 127 |
| | | (-64 - +63) |
| 48 | 0aaa aaaa | Scale Tune for G# 0 - 127 |
| | | (-64 - +63) |
| 49 | 0aaa aaaa | Scale Tune for A 0 - 127 |
| | | (-64 - +63) |
| 4A | 0aaa aaaa | Scale Tune for A# 0 - 127 |
| | | (-64 - +63) |
| 4B | 0aaa aaaa | Scale Tune for B 0 - 127 |
| | | (-64 - +63) |
|—————————————+———————————————————————————————————————————————————————————————|
|Total Size | 00 00 0C |
+—————————————————————————————————————————————————————————————————————————————+
* In order for a GS Exclusive message to be correctly received by the JV-1010, the starting address of the message must be the Start address of each Part (the address of Scale Tune C, i.e., offset
40).
