Installing the Ink Cartridges
13
1. Changes to the Setup Guide1. Changes to the Setup Guide
2. Insert the ink cartridge for each color.
SET CARTRIDGE
1 2 3 4 5 6
FILLING INK...
>>>>>>>>>>
Insert into the slot of the matching color.
* This gure indicates LEC-330.
LEC-330/540,LEJ-640
Ink mode Ink cartridges
Gloss mode
1 cartridge each of cyan, magenta, yellow, and black
2 cartridges of gloss
White mode
1 cartridge each of cyan, magenta, yellow, and black
2 cartridges of white
EUVS ink mode
Gloss/White mode 1 cartridge each of cyan, magenta, yellow, black, gloss, and white
LEF-12
・1 cartridge each of cyan, magenta, yellow, black, gloss, and white
* Selection in ink mode cannot be performed.
3. Close the ink cartridge cover.
