Using the REAC Connector Covers (S-4000S and S-4000H)
The REAC ports on the S-4000S and S-4000H units feature rugged Neutrik® EtherCon® connectors. As
discussed in Chapter 5, they can accept either standard RJ45 plugs or RJ45 plugs housed in EtherCon-
type connectors.
When using an Ethernet cable with standard RJ45 plugs (such as the cable included with the S-4000
System), fit the included REAC connector covers on the REAC ports as shown.
S-4000S
S-4000H
Remove the REAC connector covers when using Ethernet cables with EtherCon-type
connectors.
