14
Playing
Open/Closed
The hi-hat sound will change smoothly between open and closed
depending on pressure applied to the hi-hat control pedal.
Foot closed and foot splash sounds are possible.
Bow Shot
Playing the middle area of the hi-hat pad.
fig.Play-VHBow.eps
Edge Shot
Playing the edge of the hi-hat pad with the shoulder of the stick
(as shown in the figure).
fig.Play-VHEdge.eps
fig.FD-8.eps
Open Hi-Hat
Strike the hi-hat without pressing the pedal.
Half Open Hi-Hat
Strike the hi-hat with the pedal pressed half-way.
Closed Hi-Hat
Strike the hi-hat with the pedal pressed.
Foot Closed
Completely press down the pedal.
Foot Splash
Quickly hitting the hi-hat pedal (with heel or toes) and instantly
releasing it.
* Connect the FD-8 to the TD-4 before turning on the power.
Hi-Hat (CY-5)
Bow
Edge
Hi-Hat Control Pedal FD-8
TD-4_e.book 14 ページ 2008年11月5日 水曜日 午後6時40分
