Roland V-Combo VR-760 - Page 98

98
Effects/Parameter List
36: FLANGER -> DELAY
fig.02-036m
37: CHORUS -> FLANGR
(Chorus -> Flanger)
fig.02-037m
38: CHORUS/DELAY
The parameters are the same as for “35: CHORUS -> DELAY.”
However, the Delay Balance parameter adjusts the volume balance
between the direct sound and the delay sound.
fig.02-038m
39: FLANGER/DELAY
The parameters are the same as for “36: FLANGER -> DELAY.”
However, the Delay Balance parameter adjusts the volume balance
between the direct sound and the delay sound.
fig.02-039m
40: CHORUS/FLANGER
The parameters are the same as for “37: CHORUS -> FLANGR.”
However, the Flanger Balance parameter adjusts the volume balance
between the direct sound and the flanger sound.
fig.02-040m
Parameter Value Explanation
Flg Delay 0.0–100.0 ms
Adjusts the delay time from when the
direct sound begins until the flanger
sound is heard.
Flg Rate 0.05–10.00 Hz
Frequency of modulation
Flg Depth 0–127
Depth of modulation
Flg Fbk -98–+98%
Adjusts the proportion of the flanger
sound that is fed back into the effect.
Negative (-) settings will invert the
phase.
Flg Bal # D100:0W–D0:100W
Volume balance between the direct
sound (D) and the flanger sound (W)
DelayTime 0.0–500.0 ms
Adjusts the delay time from the direct
sound until the delay sound is heard.
Delay Fbk -98–+98%
Adjusts the proportion of the delay
sound that is fed back into the effect.
Negative (-) settings will invert the
phase.
Dly HFDmp 200–8000 Hz,
BYPASS
Adjusts the frequency above which
sound fed back to the effect will be
cut. If you do not want to cut the high
frequencies, set this parameter to BY-
PASS.
Delay Bal # D100:0W–D0:100W
Adjusts the volume balance between
the sound that is sent through the de-
lay (W) and the sound that is not sent
through the delay (D).
Level 0–127
Output Level
Parameter Value Explanation
Cho Delay 0.0–100.0 ms
Adjusts the delay time from the direct
sound until the chorus sound is
heard.
Cho Rate 0.05–10.00 Hz
Modulation frequency of the chorus
effect
Cho Depth 0–127
Modulation depth of the chorus effect
Cho Bal # D100:0W–D0:100W
Volume balance between the direct
sound (D) and the chorus sound (W)
Flg Delay 0.0–100.0 ms
Adjusts the delay time from when the
direct sound begins until the flanger
sound is heard.
Flg Rate 0.05–10.00 Hz
Modulation frequency of the flanger
effect
Flg Depth 0–127
Modulation depth of the flanger ef-
fect
Flg Fbk -98–+98%
Adjusts the proportion of the flanger
sound that is fed back into the effect.
Negative (-) settings will invert the
phase.
Flg Bal # D100:0W–D0:100W
Adjusts the volume balance between
the sound that is sent through the
flanger (W) and the sound that is not
sent through the flanger (D).
Level 0–127
Output Level
Feedback
Delay
L in
R in
L out
R out
Balance W
Balance W
Balance D
Balance D
Flanger
Balance W
Balance W
Balance D
Balance D
Feedback
Feedback
Flanger
L in
R in
L out
R out
Balance W
Balance W
Balance D
Balance D
Chorus
Balance W
Balance W
Balance D
Balance D
R in R out
L in L out
Feedback
Balance W
Balance D
Balance W
Balance D
Chorus
Delay
R in R out
L in L out
Feedback
Feedback
Balance W
Balance D
Balance W
Balance D
Flanger
Delay
R in R out
L in L out
Feedback
Balance W
Balance D
Balance W
Balance D
Chorus
Flanger
