Installation
EVBM-V01-R1 Installation and Operation Manual BasicCharge Intelligent EV Charging Pedestal
December 2022 Page 18 of 36
If a Ground Mounting Base Will be Used:
1. Prepare the ground and set the ground mounting base in the desired location.
x Make sure the power supply cable, the ethernet cable (if required), and the
Load Balancing CT cable (if required) are fed upward through the middle of
the base.
2. Concrete the base into place and allow time for it to set.
x The lip of the base should be 2 – 3 mm above the surrounding ground level.
If a Ground Mounting Base Will Not be Used:
1. Prepare a suitable area of firm, flat ground.
2. Use the rubber mat as template to mark where the mounting holes are to be made
in the ground.
x It must be possible to secure the chargepoint to the ground with bolts or similar
fixings that are appropriate to the type of prepared ground.
x Typically, into concrete, M8 x 100 mm Anchor Bolts should be used but installers
must assess the site and choose the most appropriate fixing for their needs.
x Make sure the power supply cable, the ethernet cable (if required), and the
Load Balancing CT cable (if required) are fed upward through the middle of
the pedestal mounting location.
3. Securing points in the prepared ground must align with pre-made holes in the base
of the pedestal. If required, the securing points can be installed using the
chargepoint as a template during the installation steps.
IMPORTANT: Only use the chargepoint as a template to mark the location of the
securing points. Do NOT drill through the pedestal into the prepared surface. Dust
and/or other contamination can damage components and will invalidate the
warranty.
