Labelling
BasicCharge Intelligent EV Charging Pedestal EVBM-V01-R1 Installation and Operation Manual
Page 15 of 36 December 2022
Labelling
Observe any/all labels displayed on the equipment or inside the enclosure.
Figure 6 Typical Product Rating and
Serial Number Label
Figure 7 Configuration Tag (Back and Front)
Figure 8 Socket ID Label
Figure 9 Front Label
Figure 10 Instructions and RFID Label
Figure 11 Typical Socket Type and
power Rating Labels
NOTES:
1. Labels shown here are typical
examples. Refer to the labels on the
equipment.
2. Labels shown here are not to scale.
3. Additional labels may be located
within the enclosure and used under
instruction of the configuration
application.
