Chargepoint Installation Completion
EVBM-V01-R1 Installation and Operation Manual BasicCharge Intelligent EV Charging Pedestal
December 2022 Page 28 of 36
4. Make sure the service providers label(s) is neatly applied, close to the appropriate
socket.
5. Test the illumination.
LED Illumination
This pedestal incorporates an amenity LED illumination lamp which activates in response to
changing light levels. To test the illumination (when power is applied to the pedestal):
1. Cover the light sensor, located on the side of the pedestal, the lamp should
illuminate.
2. Uncover the light sensor and the lamp should switch OFF.
NOTE: To prevent flickering in frequently changing light conditions such as headlights
or shade from passing vehicles, the lamp has a built-in delay before it switches on /
off.
3. If required, remove any handling marks from the enclosure with a soft, damp cloth.
4. Make sure this manual is given to the Owner/Host before leaving the site.
